All-in-one Industrial Panel PC

Industrial panel PCs integrate display, touch screen, and Intel computing hardware into a single rugged device — eliminating separate monitors, touch overlays, and external computers. AplusLCD offers Intel i3/i5/i7/i9 processors (plus low-power options such as N100, J14125, and J1900) on Windows 10/11 PRO/IoT for demanding industrial applications, with fanless passive cooling, IP65 front panels, PCAP 10-point multi-touch, and rich industrial I/O. Sizes run from 7" to 65" with 8/16/32/64/128GB RAM and 32GB-1TB storage.

One sealed unit replaces three

The panel PC replaces the three-piece architecture of monitor, touch overlay, and industrial box PC with one sealed unit — a benefit that is measurable on the factory floor. There is no consumer cooling fan to pull dust into the electronics: fanless passive cooling keeps the enclosure sealed, silent, and maintenance-free through years of 24/7 operation. The IP65-rated front panel shrugs off water spray, oil mist, and cleaning chemicals, while the rear mounts through a standard panel cutout or on a VESA arm. Integration simplifies too — one device needs one power feed, one set of mounting hardware, and one image to manage, instead of three components with three different lifecycles.

Android display or Intel panel PC?

Choose the Intel panel PC when the application depends on the Windows industrial ecosystem — SCADA and MES clients, legacy Windows drivers for PLCs and instruments, machine-vision frameworks, or proprietary factory software that has no Android equivalent. Choose an Android display when the deployment is a kiosk, menu board, or interactive terminal that only needs a modern app runtime and lower hardware cost.

Within the Intel range, match the processor to the workload: Celeron-class N100/J1900 options handle HMI and light SCADA; Core i3/i5 covers multi-window control rooms and data logging; i7/i9 provides the compute for machine vision and heavy analytics at the edge.

The peripheral story decides the platform

AplusLCD panel PCs carry native COM (RS-232/485) ports that talk directly to PLCs, barcode scanners, and weigh scales, plus multiple USB, Gigabit Ethernet, and HDMI for cameras and secondary displays. RAM from 8GB to 128GB and storage up to 1TB accommodate growing data retention and logging requirements, and Windows 10/11 PRO/IoT gives the IT team full domain join, GPO, and remote-management compatibility. Every unit is assembled and burned in at our ISO 9001 plant, ships with no MOQ for the first evaluation unit, and is supported by engineers who advise on mounting, I/O pinout, and image deployment for your specific line.

Selecting resolution, brightness, and enclosure

Three specifications settle most panel PC projects. Resolution comes first: a 1920x1080 panel PC covers HMI screens, SCADA dashboards, and machine-vision previews at native scale, while 1024×768 units remain the economical choice for simple operator terminals. Brightness follows the ambient light — indoor control rooms are served by 300-500 nits, but a 1000 nit panel PC with optical bonding and anti-glare glass holds its contrast behind glazed facades, in bright lobbies, and under daylight. Enclosure closes the list: an outdoor kiosk panel PC pairs a 1000-1500 nit high-brightness panel with IP65 front sealing, a wide-temperature Intel board, and a bonded anti-reflective cover glass, so the same unit survives sun, rain, and temperature swing. Send us the ambient light, cutout size, and resolution you need, and our engineers will configure the exact panel PC for your line — with a single evaluation unit available before any volume commitment.

AplusLCD manufactures industrial panel PCs in our own ISO 9001 plant, which lets OEM partners specify the computing core, memory, storage, I/O, touch, and enclosure finish as a single engineered product rather than a modified catalogue item. Typical OEM work includes preloading and licensing a customer Windows image, provisioning software with IT-management defaults, adding custom COM or USB port layouts, printing brand logos and control markings on the bezel, and matching the front finish to the machine or kiosk it controls. Because we build to order, the hardware matches your software and mounting design from the first unit, not after a long qualification cycle on a stock PC.

Panel PC OEM programmes follow an evaluation-first path: a single sample with no MOQ is configured exactly as production will ship it — your OS image, your I/O, your bezel — and run through 24/7 burn-in so integration risk is retired before volume begins. Approved programmes scale from pilot batches to production at 200-300 units per day with full component traceability and long-term availability commitments that match industrial equipment lifecycles. Volume pricing, private-label branding, and custom engineering are quoted up front with no hidden fees.
