Overview
AplusLCD provides specialized ATM display solutions engineered for the demanding financial self-service environment. Our ATM replacement monitors are designed as drop-in replacements for major OEM equipment including NCR 5684/5685/5884/5885/5870/5886/5887 series and Wincor 5005L terminals, offering a seamless upgrade path with improved display quality and long-term availability. With over 15,000 displays deployed in ATMs across 20+ countries, our solutions are trusted by leading financial institutions for mission-critical cash-dispensing operations worldwide.
Common ATM & Banking Display Problems — and How We Specify Around Them
What we specify: Specify a drop-in replacement rather than a machine retrofit. Our AP-series units match the original mounting points, connector positions and bezel dimensions for NCR 5684/5685/5884/5885/5870/5886/5887 and Wincor 5005L, stay in continuous production, and carry long-term availability commitments that protect a deployed fleet.
What we specify: 1000-1500 cd/m² with optical bonding and anti-reflective cover glass for any screen facing a window or open sky. 300-500 cd/m² is enough for indoor lobbies, so do not over-specify brightness you do not need.
What we specify: Tempered 6 mm cover glass, sealed reinforced mounting and an IK-rated build. We certified a 15" PCAP unit to the IK-10 impact rating at an accredited laboratory with zero NRE cost for the customer.
What we specify: Keep VGA, DVI, HDMI, DP, AV, BNC and USB on the interface list, and let us match the original LVDS pinout so the replacement panel runs plug-and-play with the controller already in the machine.
What we specify: There is no MOQ — start with sample units for compatibility testing on your exact ATM model, then scale. Standard configured orders typically ship within 2-4 weeks.
ATM LCD Display Replacements for NCR & Wincor Machines
Upgrading an aging or failed ATM screen does not require replacing the machine. AplusLCD ATM LCD display replacements are engineered as mechanical and electrical drop-in fits for NCR and Wincor terminals, covering NCR 5684, 5685, 5884, 5885, 5870, 5886 and 5887 machines plus Wincor 5005L ATMs. Each replacement monitor matches the original mounting points, connector positions and bezel dimensions, so banks and ATM service providers swap in the new display without modifying the enclosure, changing wiring or re-certifying the installation. Standard AP-series units such as the 8" AP-08OPLDT1R, 12" AP-12OPNCN1 and 15" AP-15OPLAT1R remain in continuous production, are burn-in tested for 24/7 banking duty, and are supported with long-term availability commitments that protect deployed fleets from OEM parts obsolescence.
LCD Displays for ATM Machines: Sizes, Compatibility & Ordering
ATM LCD displays are available from 8" to 21.5" to fit everything from compact cash dispensers to full-function deposit and recycling terminals. Across NCR and Wincor fleets, 12" and 15" are the two most widely used ATM screen sizes — 8" serves compact dispensers, while 17" to 21.5" appears on deposit and recycling terminals. Resolutions run from 800×600 to 1920×1080 and brightness from 300 to 2000 cd/m² for bank lobbies, semi-outdoor vestibules and direct-sunlight drive-through installations. Interface choices include VGA, HDMI, DVI, DisplayPort, AV, BNC and USB, and custom LVDS pinouts can be matched to your existing ATM controller for plug-and-play operation. Because the same visible size can still hide a different pinout, backlight voltage or bracket, confirm the original panel part number before you order. Ordering is straightforward: there is no strict MOQ, sample units are recommended for compatibility testing on your exact ATM model, standard configured orders typically ship within 2-4 weeks, and custom brightness and touch options are quoted on request.
Send us your ATM model or panel numberATM Display Technology Requirements
ATM displays must meet stringent requirements for 24/7 operation in public environments. Key technical considerations include vandal-resistant surface treatments, high reliability with long MTBF ratings, consistent color reproduction for brand identity, and compatibility with legacy video interfaces. Our monitors undergo rigorous burn-in testing to ensure years of trouble-free operation in high-usage scenarios.
Compatibility & Drop-in Replacement
Our ATM monitors are designed with exact mechanical compatibility for leading ATM models. Each unit matches the original mounting points, connector positions, and bezel dimensions. This enables banks and ATM operators to upgrade aging displays without modifying the ATM enclosure, reducing deployment time and eliminating costly re-certification. We maintain a comprehensive compatibility database covering NCR 5600 and 5800 series, Wincor 5000 series, and Diebold ATMs.
Custom Configuration Options
Every deployment environment is unique. We offer custom brightness settings from 300 to 1500 cd/m² for indoor and semi-outdoor ATMs, optional PCAP touch integration for modern multi-function ATMs, custom LVDS pinout matching, and anti-glare or anti-reflective surface treatments. Our engineering team works directly with your technical staff to ensure plug-and-play compatibility with your existing ATM controller boards.
Selection Parameters — What to Specify for ATM & Banking
| Parameter | Specification |
|---|---|
| Screen Size | 8" to 21.5" 8"-15" covers cash dispensers and mono-function ATMs; 17"-21.5" for deposit, recycling and multi-function terminals. |
| Resolution | 800×600 to 1920×1080 800×600 keeps legacy controller compatibility; 1920×1080 for multi-function terminals running on-screen marketing. |
| Brightness | 300 to 2000 cd/m² 300-500 cd/m² for indoor lobbies; 700-1000 for semi-outdoor vestibules; 1000-1500 with optical bonding for drive-through units facing direct sun. |
| Touch Technology | PCAP/IR/SAW/Resistive PCAP for multi-function ATMs; resistive where service staff work in gloves; IR/SAW for larger apertures. |
| Video Interface | VGA, HDMI, DVI, DP, AV, BNC, USB Match the existing ATM controller — custom LVDS pinout is available so the new panel runs plug-and-play. |
| Operating Temperature | -20°C to 70°C Standard range covers most sites; specify wide-temp plus a heater option for unconditioned outdoor vestibules. |
| Panel Type | TN / IPS TN for cost-driven indoor retrofits; IPS where the screen is viewed off-axis from a drive-through lane. |
Which AplusLCD Display Fits Your ATM & Banking Project?
Drop-in units for NCR 5684/5685/5884/5885/5870/5886/5887 and Wincor 5005L, 8" to 21.5", matched to the original mounting points, connector positions and bezel dimensions.
View models & specifications
Bare 6.5"-19" chassis that mounts behind the ATM fascia on your existing bracket points — the route to take when the front bezel stays with the machine.
View models & specifications
IP65 aluminium front bezel with a 6 mm tempered cover glass option and sealed reinforced mounting for lobbies and unattended public sites.
View models & specificationsThe technology guides behind these specifications
Not sure which of these fits your atm & banking project? Send size, brightness, mounting method and site environment — our engineers return a configured quotation with pricing and lead time within 24–48 hours.
Request a QuoteApplications
Related Industry Applications
Robust touch-enabled displays for ticketing kiosks, check-in terminals, information boards and retail self-service machines. IP65-rated options for outdoor and high-traffic environments.
Slim, reliable display solutions for point-of-sale terminals, customer-facing screens, electronic shelf labels and retail digital signage. Android or Windows platform support.
Frequently Asked Questions
Can your ATM displays replace the original NCR or Wincor monitor directly?
Yes. Our AP series ATM displays are designed as mechanical drop-in replacements for NCR 5684/5685/5884/5885/5870/5886/5887 and Wincor 5005L models, matching original mounting dimensions and connector positions.
What is the minimum order quantity for ATM displays?
We have no strict MOQ. For new customers, we can start with sample units for compatibility testing. Typical pilot orders are 5-10 units, and we have flexible production scaling for volume orders.
What brightness level is recommended for outdoor or drive-through ATMs?
For outdoor or drive-through ATMs exposed to direct sunlight, we recommend 1000-1500 cd/m² brightness with optical bonding to reduce internal reflections. Indoor ATMs in bank lobbies typically require 300-500 cd/m². All brightness levels can be customized to match your specific installation environment.
Do you offer extended warranty and maintenance plans for ATM displays?
Yes. AplusLCD supports ATM deployments with a tiered warranty program: 12 months standard warranty from delivery date against manufacturing defects, plus optional extended coverage up to 1 year for qualifying projects including advance replacement service. Given the critical nature of ATM operations, we provide priority technical support for urgent deployment issues and maintain strategic spare-parts inventory for rapid fulfillment.
How fast can you ship a replacement ATM display?
Standard configured ATM displays typically ship within 2-4 weeks. For an outage we can prioritise a single replacement unit from ongoing production. Send the ATM make, model and a photo of the failed screen and we will confirm availability, compatibility and lead time.
Can you build an ATM display for a model that is not on your compatibility list?
Yes. Send the machine model, the mechanical drawing or the failed unit itself, and our engineers will confirm whether an existing AP-series display fits or quote a custom build matched to your mounting points, connector positions and LVDS pinout. There is no MOQ, so the first unit can be a sample for compatibility testing before you commit to a fleet order.
